Moreplex TV is a Direct To Home (DTH) TV platform which is the new dawn of Pay TV Services that is redefining the entertainment television for the one billion people in Africa. We are providing a multipurpose Free To Air (FTA), Free To View (FTV) and Pay TV services that comprise DTH, Digital Terrestrial TV (DTT) and Video On Demand (VOD).
Signal Installation Software
Installation signal parameters to track are:
frequency 11090 V SR: 30000 Or 11170 H SR: 30000.
Send firmware to a FAT32 (not NTFS) formatted drive;
– Insert Pen Drive into USB port of STB; and
– Power cycle STB and watch out for the flashing
green indicator light.
– Remove the pen drive.
ENABLING THE DISEQC FEATURE
The procedure: Follow the URL link to access/download the Diseqc Software onto a FAT32 Pen/USB drive;
Ensure that a four (4) way Diseqc is in place;
Ensure to have satellite antenna(s) pointed to any two (2) or all the following Satellite:
II. ASTRA 2F
III. NIGCOMSAT/AMOS 17
IV. INTELSAT 20
Terminate RF cables from the antennas on the input ports of DISEQC as shown in the figure above (i.e. Berlintersat => Port 1; Astra 2F => Port 2; NigComSat/Amos 17 => Port 3; and Intelsat 20 => Port 4;
Insert Pen/USB drive with Diseqc Software into STB;
Power cycle (turn off and on) STB respectively;
STB will go into auto scan mode, however, if it doesn’t, kindly push the menu button in this order Menu => Installation Setup => Satellite Scan and push OK to scan.
